Lifting stroke (m) |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
Lifting speed (mm/min) |
1500 |
||||||
Optional extension stroke (m) |
2~4 |
2~6 |
3~7 |
3~8 |
3~8 |
3~8 |
4~8 |
Extension speed (mm/min) |
100~1000 (VVVF) |
||||||
Max. load at boom end (kg) |
500 |
||||||
Rotating angle (°) |
±180 |
||||||
Rotating speed (r/min) |
0.02~0.2 (VVVF) |
||||||
Locking mode |
Mechanical lock and Motor brake |
||||||
Speed of trolley (mm/min) |
250~2500 (VVVF) |
||||||
Center distance of rail (mm) |
P43/2500 |
Note: The above parameters are for TIME standard heavy duty manipulator configurations, and can be customized according to the customer's requirements.
