Selection principle of strip cladding welding equipment
Model |
TIME: TFD 30-ESK-75 or Soudokay: SK 30-ESK-75 |
TIME: TFD 60-ESK-75 or Soudokay: SK 60-ESK-75 |
TIME: TFD 125-ESK-300 or Soudokay: SK 125-ESK-300 |
Strip width (mm) |
30 |
30、60 |
30、60、90、120 |
Minimum Dia.(mm) |
Longitudinal:Φ380 Circumferential:Φ450 |
Longitudinal:Φ450 Circumferential:Φ650 |
Longitudinal:Φ650 Circumferential:Φ800 |
Welding current (A) |
SAW:380~500 ESW:450~650 |
SAW:650~950 ESW:850~1250 |
SAW:650~950 ESW:850~1250 |
Arc voltage (V) |
SAW:27~32, ESW:22~25 |
||
Cladding linear speed (mm/min) |
SAW:100~120, ESW:110~130 |
||
Wire feeder |
TFD (TIME), NA-3SF (Lincoln), A6(Esab) |
