發布日期:2016-04-17
型 號 |
TRS-I250 |
TRS-I500 |
TRS-I1000 |
TRS-I1500 |
TRS-I2000 |
額定有效載荷 |
500 |
500 |
1200 |
1500 |
2500 |
額定輸出扭矩(N*M) |
1078 |
1078 |
2816.5 |
4198.7 |
4198.7 |
額定轉動慣量GD^2/4(kg*m^2) |
125.8 |
292.9 |
657 |
956 |
1460.3 |
回轉角度( °) |
±360° |
||||
回轉速度 |
56°/sec |
56°/sec |
56°/sec |
42.8°/sec |
42.8°/sec |
許用夾具重量 |
250 |
500 |
1000 |
1500 |
2000 |
變位機回轉半徑 |
700mm~1000mm |
||||
夾具安裝長度 |
1600mm~3500mm |
